MEKO A-100

Initial Operational Capability (IOC) : June 2006
Total Production : 11

Model Status Year Produced
MEKO A-100 Active 2006 7
MEKO A-100 IN Active 2020 4



MEKO A-100

Group : Corvettes
Status : Active
Also Known As : Gawron, Kedah, MEKO 100 RMN, NGPV (RMN designation - Next Generation Patrol Vessel), Project 621
Origin : Germany
Contractors : Blohm + Voss GmbH*, Boustead Naval Shipyard, PGZ Stocznia Wojenna
Initial Operational Capability (IOC) : June 2006
Total Production : 7

The MEKO A ships are the next generation of surface combatants evolved from the MEKO-family and offered by Germany for the export market. They will accommodate advanced propulsion systems, sensors and weaponry while providing improved survivability using low-observable technologies and design. Retrofit and upgrade processes will be easily carried out thanks to a modular open architecture and cutting-edge construction techniques.

The MEKO A-100 corvettes have been designed to perform a wide variety of missions. According to customer specifications the MEKO A-100 ships will feature a displacement ranging from 800 to 2,500 tons. They can accommodate a medium size helicopter, vertical launched missiles (16), 8 anti-ship missiles, Close-In weapons, and small caliber guns. The Polish Navy procured only one ship under the Project 621 Gawron-class built by PGZ Stocznia Wojenna.

Operators
Country Status State Notes
MalaysiaActive 6/6
PolandActive 1/1
Specifications
Notes
Crew 94
Number of Weapons 24
Dimensions
Beam 13.4 meter
Length 90.6 meter
Main Gun Caliber 76 millimeter
Mass
Full Displacement 1,900 ton
Performance
Max Range 7,400 kilometer
Speed
Top Speed 29 knot
Gear
Anti-Ship Missiles
RBS15 Mk3
Naval Gun Systems
76/62 Compact1
Radar Systems
TRS-3D/16 ES1
Sea-Based Air Defense Systems
Mk-31 RAM1
Ship Power Plants
LM25001
Surface-to-Air Missiles
ESSM
Torpedoes
MU90 Impact
Listing
Ship Status Com Decom
171 KD Kedah Active June 2006
172 KD Pahang Active August 2006
173 KD Perak Active 2007
174 KD Terengganu Active 2008
175 KD Kelantan Active 2009
176 KD Selangor Active 2010
Kujawiak Cancelled 2016
Krakowiak Cancelled 2017
Mazur Cancelled 2017
Kurp Cancelled 2018
Goral Cancelled 2018
241 ORP Slazak Active November 28, 2019



MEKO A-100 IN

Group : Corvettes
Status : Active
Also Known As : Saar 6
Origin : Germany
Contractor : Blohm + Voss GmbH
Initial Operational Capability (IOC) : November 11, 2020
Total Production : 4
Unitary Cost : EUR €300 million

The Israel Navy's four MEKO A-100 stealth class corvettes were ordered in December 2014 as part of renewal of its fleet and to protect Israel's offshore gas facilities in the Eastern Mediterranean. ThyssenKrupp Marine Systems will built these missile boats under a 1.2 billion euro contract with Germany paying 300 million Euro and Israel the remaining 900 million Euro. Israel plans call for these ships to be fitted with undisclosed sensors and weapon systems produced locally by Israel companies thus boosting its combat capabilities. The procurement contract for four vessels was signed in late December 2014 with the ships to be commissioned by 2020.

Operators
Country Status State Notes
IsraelActive 4/4
Specifications
Notes
Dimensions
Beam 13 meter
Length 90 meter
Mass
Full Displacement 1,900 ton
Gear
Radar Systems
EL/M-2084 MMR1
EL/M-2248 MF-STAR1
Sea-Based Air Defense Systems
Barak 8 AMD1
C-Dome1
Surface-to-Air Missiles
Barak 35
Barak 70
Barak ER
Tamir40
Listing
Ship Status Com Decom
INS Magen Active November 11, 2020
INS Oz Active May 4, 2021
INS Atzmaut Active July 27, 2021
INS Nitzachon Active July 27, 2021

News

Thursday, 11 April, 2024
Israel Navy C-Dome Scores First Interception at Sea

Haifa, Israel – Overnight, the Israeli Navy successfully deployed RAFAEL’s C-DOME™ to intercept a suspicious hostile target which posed a significant threat to Israeli assets

Wednesday, 30 November, 2022
Israeli Navy Successfully Test Fires Barak LRAD Against Advanced Cruise Missile Target

The robust long-range interceptor was launched from an Israeli Navy Sa'ar 6-class corvette The Israeli Navy, the Directorate of Defense Research and Development (DDR&D)

Tuesday, 27 July, 2021
Israeli Navy Takes Delivery of Last Two Saar 6 Class Corvettes

thyssenkrupp Marine Systems has handed over the two ships to the Israeli Navy today. The SA`AR 6-class corvettes had been christened earlier.

Sunday, 4 July, 2021
IAI Integrating Barak MX Air Defense System on Saar 6 Corvettes

Naval battle systems, including the MF-STAR (Magen Adir) radar, are being installed on the Israel Navy’s Sa'ar 6 premier defense warship, and will provide a layer of defensive

Wednesday, 11 November, 2020
Israel Navy Takes Delivery of First Saar 6 Corvette

On November 11, 2020 world’s most modern corvette “INS Magen” was officially handed over by thyssenkrupp Marine Systems to the Israeli Navy.

Wednesday, 15 August, 2018
Israeli Navy Selects Barak 8 Air and Missile Defense System for Saar 6 Class Corvettes

Israel Aerospace Industries (IAI) has entered an agreement to provide advanced defense systems to Israel Navy's Sa'ar-6 corvettes.

Tuesday, 7 August, 2018
Israeli Navy Orders Electronic Warfare Suites for Saar 6 Corvettes

Elbit Systems Ltd. (NASDAQ: ESLT and TASE: ESLT) ("Elbit Systems" or "the Company") announced today that it was awarded an approximately $85 million contract from the Israeli

Friday, 28 April, 2017
FMS: Israel Seeks 76mm Naval Guns for Saar 4.5 and Saar 6 Missile Boats

WASHINGTON, Apr. 28, 2017 - The State Department has made a determination approving a possible Foreign Military Sale to Israel for 76mm Naval Gun and Technical Support.

Wednesday, 29 March, 2017
Israel Navy Saar 6 Corvettes to Feature Two Iron Dome Launchers

The Israeli Navy will include extra “Iron Dome” missile launchers on its Sa’ar 6 missile ships being manufactured in Germany.

Wednesday, 26 March, 2003
Blohm + Voss Shipping the First Patrol Vessel for Malaysia

The first of 6 patrol vessels ordered by the Royal Malaysian Navy and built by Blohm + Voss shipyards has been floated in a dock ship at Blohm + Voss' facilities in Hamburg.

Photo Gallery

Notes

* Prime Contractor
State Latest Known holdings/Original Procurement
Com - Date of Commissioning
Decom - Date of Decommissioning
