Project 11661

Initial Operational Capability (IOC) : 2004
Total Production : 9

Model Status Year Produced
Project 11661 Active 2004 9



Project 11661

Group : Frigates
Status : Active
Also Known As : Cheetah, Dinh Tien Hoang (Vietnamese Navy), Gepard-3.9, Project 11661K, Tatarstan
Origin : Russia
Contractors : Zelenodolsk Design Bureau, Zelenodolsk Shipyard
Initial Operational Capability (IOC) : 2004
Total Production : 9

The Project 11661 Gepard-3.9 is a small displacement frigate designed to engage surface and underwater ships as well as airborne threats safeguarding maritime borders and exclusive economic zones (EEZs). They are the replacement for Soviet Koni, Parchim and Grisha corvette designs. The first ship was nearly complete in 1995 but the lack of funds in Russia delayed her commissioning. Vietnam ordered two of these small frigates in 2001.

The Project 11661 is equipped with sophisticated sensors, weapon systems and a flight deck and hangar for one Ka-28 or Ka-31 helicopter. The main propulsion system consists of two-shaft Combined Diesel or Gas (CODOG) each developing 11,000-hp. The weapon system includes 16 4x4 Uran/3M24 anti-ship cruise missiles; one 76mm AK-176M naval gun that can be replaced by the A190E 100mm naval gun; three Palma close-in weapon systems; two 14.5mm machine guns; two 533mm two-tube torpedo launchers; and one RBU-6000 12-tube anti-submarine rocket launcher. The Uran missile system was replaced by the Kalibr-NK beginning with the Russian Navy's Dagestan frigate.

Operators
Country Status State Notes
RussiaActive 3/3
Sri LankaPlanned ? At least two ships to be ordered in 2017 (Gepard 5.1)
VietnamActive 4/6 Two ships ordered in 2005 and another two ordered in February 2013. The ships ordered in February 2013 feature anti-submarine weapons and an advanced propulsion system.
Specifications
Notes
Crew 103
Number of Aircraft 1 Ka-28 or Ka-31
Number of Engines 3 2 gas turbine + 1 diesel engine
Dimensions
Beam 13.1 meter
Draft 5.3 meter
Length 102 meter
Main Gun Caliber 76 millimeter
Mass
Full Displacement 2,500 ton
Standard Displacement 2,200 ton
Performance
Max Range 5,000 nautical mile at 10 knots
Power
Boost Power 22,600 kW
Cruise Power 5,890 kW
Speed
Cruise Speed 18 knot
Economical Speed 10 knot
Top Speed 28 knot
Time
Mission Endurance 20 day
Gear
Anti-Ship Missiles
3M54E16
3M54TE116
Uran16
Anti-Submarine Rockets
91RE116
91RTE216
RPK-81
ASW Helicopters
Ka-281
Cruise Missiles
Kalibr-PL16
Maritime Helicopters
Ka-311
Missile Launchers
3S-142
Naval Gun Systems
AK-176M1
AK-630M2
Radar Systems
3TS-25E1
Mineral-ME1
Pozitiv-ME11
Pozitiv-ME1.21
Sea-Based Air Defense Systems
Palash1
Palma3
Listing
Ship Status Com Decom
691 Tatarstan Active 2004
693 Dagestan Active June 2012
416 Burevestnik Active 2013
HQ-011 Dinh Tien Hoang Active March 5, 2011
HQ-012 Ly Thai To Active August 22, 2011
HQ-015 Tran Hung Dao Active September 2017
HQ-016 Quang Trung Active November 2017
#5 Planned 2028
#6 Planned 2029

News

Sunday, 19 November, 2017
Russian Navy Tests Palash and Palma Air Defense Systems in the Caspian Sea

The provisional enemy targets were hit with Palash and Palma air defense guns and AK-630 close-in weapon systems as soon they reached the ships' firing range during the drills

Friday, 24 March, 2017
Sri Lanka to Buy Gepard-3.9 Class Corvettes

Russia and Sri Lanka have reached final stages of agreeing on a contract to deliver Gepard 3.9-class frigates to Colombo, a source in the field of military and technical

Wednesday, 7 October, 2015
Russian Caspian Sea Flotilla Strikes ISIL Targets in Syria with Kalibr Cruise Missiles

The Russian Ministry of Defense has released video footage showing its nighttime cruise missile strikes from the Caspian Sea against Islamic State targets in Syria.

Thursday, 24 May, 2012
Russian Navy Gepard-Class Frigate Tests Successfully Kalibr-NK Missile System

Russia’s second Gepard class frigate has successfully test-fired missiles from the new Kalibr-NK missile system during the first stage of sea trials in the Black Sea, a spokesman

Photo Gallery

Notes

* Prime Contractor
State Latest Known holdings/Original Procurement
Com - Date of Commissioning
Decom - Date of Decommissioning
